etherCUT-BT - MANUAL L1 PHYSICAL LEVEL ETHERNET BREAKER
etherCUT-BT/* a hardware module for manual physical breaking of an industrial Ethernet network. Module structurally combined with cam switch. Available in two models:
- etherCUT-BT - control cabinet door mounting
- etherCUT-BT/DIN - DIN rail mounting
MODEL FEATURES
- Does not require power supply
- Dry contacts for monitoring the state of the breaker
- Personnel management
- The maximum length of the Ethernet line is 100 meters
- The possibility of sealing Ethernet patch cords
- How the module works
- An album of diagrams for designers
etherCUT-BT/* is equipped with two RJ-45 connectors for connecting the backbone of the industrial Ethernet network BASE-T. etherCUT-BT/* does not require external power supply. The breaker has two separate pairs of terminals for connecting dry DI contacts (voltage 24-220V) to transmit information about its state to the ICS. The package includes seals for sealing connected network cables.
- Operating temperature -40 +45 °C
- Degree of protection IP30
- Overall dimensions L*W*H, mm 105*74*77
- Supported PoE classes 0,1,2,3,4
